Mango Power S Plug-In PV
Mango Power S Plug-In PV (PIPV) is a plug-in photovoltaic system for the US market. It uses a single-stage cyclo microinverter: a ground-mounted PV array that connects to a standard outdoor receptacle.
System configuration
Section titled “System configuration”US configuration: 120 V / 1,200 W, comprising four 120 V / 300 W modules. Each module’s microinverter is configured for PIPV at 120 V / 280 W AC output; that is not the S Pro 240 V / 500 W nameplate. Details are in FAQ.
Electrical, mechanical, and cable-kit ratings are listed under Specifications. Installation steps are in Installation.
1200 W kit
Section titled “1200 W kit”| Included | Role |
|---|---|
| 4 × 300 W solar panels | Capture sunlight in a balcony, patio, backyard, or similar space |
| Mango Power S Pro microinverters (PIPV firmware) | Convert each panel to 120 V AC; 280 W nominal output per unit |
| Solar panel stands | Support outdoor placement |
| Mango Power S Cable PIPV 4-in-1 | Connects the four modules as one plug-in string |
| Smart Gateway Lite | Home use, solar production, and grid flow, with optional anti-backflow / zero-export |
| Mango Power app | Real-time energy data |
Features
Section titled “Features”- 97% CEC efficiency
- One-click Wi-Fi Mesh (2.4 GHz)
- Restricted-grid certification; listed standards are in Specifications
- Enclosure rating NEMA Type 6P / IP68
- Estimated savings of $420 per year and more than $10,000 over the product lifetime
- 15-ton CO₂ offset over the product lifecycle
Warranty
Section titled “Warranty”- Microinverter and PV module: 25 years
- Cable kit: 3 years
Limited warranty. Terms are as stated in the product datasheet.
