User Manual
The 200 W Solar Move manuals cover charging Mango Power Union (Power Move / Power Home) and Mango Power E through MC4. Multiple 200 W panels may be used in series or parallel; follow the power-station user manual for the allowed connection method.
Mango Power E solar input is 60-150 V DC, 20 A max, 2000 W max. Keep string voltage within 150 V.
Is Solar Move water-resistant?
The 200 W Solar Move uses water-resistant material. Waterproof level is IP67.
Can I use multiple 200 W Solar Move panels to charge Union or E?
Yes. Check the Union or E user manual for series vs parallel limits before connecting.
How long does it take to recharge?
Times depend on panel angle and weather.
| Setup | Power Move | Power Home | Mango Power E |
|---|---|---|---|
| 400 W set (2× 200 W) | around 5.75 hours | around 11.5 hours | around 8.83 hours |
| 800 W set (4× 200 W) | around 2.88 hours | around 5.75 hours | around 4.41 hours |
The 400 W set times apply to 2× 200 W; the 800 W set times apply to 4× 200 W.
In the box (200 W)
Section titled “In the box (200 W)”200 W solar panel, protective case, user manual.
Ratings for all three models are in Specifications.
