mPanel Pro
mPanel Pro is an electrical control distribution box for Mango Power Union and Mango Power E. It connects the power station to the load and switches energy supply between the grid and backup. Two Mango Power E units in parallel can support 240 V split-phase.
Ratings are in Specifications. Safety, wall mounting, wiring, backup mode, and grid mode are in the User Manual.
Features
Section titled “Features”- Mains input 120 V / 240 V, 50 A
- Backup input 2× 30 A; output 2× 30 A; load output 4× 15 A
- Rotary switches select grid or backup for four output circuits
- Size 554 × 280 × 108 mm
- Working temperature -10°C - 45°C
